应用与筒介/Purpose and introduction：

NQGF型西林瓶粉针洗烘全自动灌装机轧盖标贴签对接线 由QCL系旋转式超声纳的清洗波洗瓶机、AQMR隧道口式热气再巡环无菌烘烤箱、NQFGX系数控内外螺杆式粉剂全自动灌装机机、NQ-50轧盖机、NQWTB-120标贴签发动机组成，也可单人在使用。满足于7-25ml规格尺寸的西林瓶粉针的产出。能实现消防喷淋充水、超声纳的清洗波粗洗、瓶壁有水擦洗、瓶壁有不间断三次再巡环水擦洗、一下吹气、一下清爽水擦洗、不间断三次吹气、瓶壁有吹气、的清洗、打火、晒干无菌去热原、空气冷却、全自动灌装机、加塞、轧盖、标贴签等二十几个道环节。NLGF schering bottles booster injection wash baked repackaging rolling cover labeling line consists of QCL series vertical ultrasonic bottle washer, ASMR tunnel type hot air circulation oven. NFFGX series CNC screw powder filling machine, NF-50 rolling machine, NFWTB-120 labeling machine, and also can be used stand-alone. Suitable for 7 to 25 ml specification schering bottles of water production. Can finish the spray water injection, ultrasonic thick bottle washing, the outer wall of water flushing, bottle wall continuous secondary circulating water flushing, a blowing, a fresh water rinse, two consecutive bottle blowing, blowing the outer wall, preheating and drying sterilization to pyrogen, cooling, packaging, gasser, cover, labeling and so on more than 20 procedures.

优势特点/characteristic：

◆洗瓶机使用机器手夹瓶，符合不同技术参数的西林瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of schering bottles;◆洗瓶选择水蒸汽喷针往复运动监控放方法，洗作用好，降低燃料。并应设针架防震动设备，增强喷针放玻璃瓶的准确的度，提高断针物理现象会出现；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶整块雾气聚氨酯保温管、喷针已经独特分着，以免了交叉式被污染，包含GMP标准化规范要求；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶丝杆前可以加装部件实现缓存数据块，有保护的丝杆，才能减少碎瓶用途；Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottle;◆洗瓶机出瓶所采用布局进口商同时进行带，接拨瓶块运输西林瓶，行驶维持可以信赖；Pieces out of the bottle inside the whole import synchronous belt, the connection dial the bottle conveying schering bottles, operation is stable and reliable;◆真空烘箱选择制热巡环蒸汽加热，温度表均衡，绿色建筑；Oven adopts hot air circulation heating, temperature uniformity, energy saving;◆恒温干燥箱要设防有时候关电养护功能性。行驶安全性高；Mixer oven has suddenly loses power protection function. Run security;◆烘烤箱可配不断循环散热控制系统，不不足房排风量，限制房的压力差不稳定平衡的危害性变凉效用好；Mixer oven can match circulating water cooling device, not loss room air volume, reduce the risk of differential pressure imbalance in room cooling effect is good.◆烘干箱可配风气体压力重新动动态平衡机上下调整体系缩短房间内和烘干箱的风气体压力不动动态平衡机导致的低温段偏差，灌装生产线间洗烘间温度表升高的一系统的问题；Mixer automatic oven can match differential pressure balance control system to reduce the room and high temperature oven pressure difference caused by the imbalance of period of migration, filling between wash between baking temperature and so on a series of problems;◆干燥箱要设DOP判断模块(也包括气压、风力、灰尘粒子束判断口)；Mixer oven with DOP test interface (including wind pressure, wind speed, dust particle detection);◆烤箱降温段可带高清在线过滤除菌系统(FDA特选)；Mixer oven cooling segment with the function of sterilization (FDA selected);◆烘干箱网带可带mri涉及CIP线下清晰体系；Type mixer oven mesh belt with ultrasound scanning CIP online cleaning system;◆干燥箱内腔室可对其进行全多方面、多的视角高压低压水清洗阴道；In pieces inside the oven chamber can be all-round, multi-angle high-pressure water flushing;◆包装机进行国际联盟更先进的的设计制作心理，包括极线速度，并且分瓶准确性，撤换标准件便；Mixer racking machine adopts the most advanced design concept, high speed, and bottles of accurate, replacement of a convenient;◆分开包装机使用交换伺服线束减速机带动分开包装罗杆翻转，装量精准；Mixer racking machine adopts ac servo motor drive the repackaging screw rotation, the load accurately;◆散装机通过装量的懂得调整直接性在触感屏上确保；Mixer packer adopts the load adjustment directly on a touch screen;◆分开包装机可选择配百级巡环式层流罩；Mixer packer optional circulating laminar flow hood best level;◆灌装机无瓶中断灌装，无瓶不添加塞的功能。Racking machine without stop packing bottle, no bottle no stoppered function.◆整线选用PLC总掌控、调频器、摸屏掌控技巧，执行不稳定性稳定。摸屏可出现各单机手机游戏的执行情况下，各掌控点的水管打压、大气压力、风压气压、温等出现，各按钮情况下和报警出现，报警自行原因和报警讲解及来排除方案。使这个生产销售的环节高达定时化掌控，联线具备着自动化控制和平系统，以确保生产销售的均衡性稳定。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. Make the whole production process automation control, on-line has the automatic balancing device, ensure production equilibrium is reliable.按照其老客户的须得，还可供加装：According to the needs of customers, but also available for selection:◆西门子PLC、施耐德开关、三凌、台达等企业品牌操作系統；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气各种压力、水的温度及mri波比强度、尘灰a粒子、流速在线视频测试、告警、登记、彩打系统；Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system;◆ORABS、CRABS、无茵隔绝器设备。ORABS, CRABS, aseptic isolator system.

系统参数设置：/technical parameters

参数 model

产生作用production capacity

洗瓶良好率率Washing bottle percent of pass

洗瓶损坏率Washing bottle breakage

灭菌方法室温sterilizing temperature

灌装误差率The repackaging of error

加塞通过率率Gasser percent of pass

新鲜空气层流卫生度Laminar air cleanliness

正空抽速Vacuum pumping speed

电阻量 capacitance

供电power supply

总电量显示Total transmission energy

外表尺寸规格boundary dimension

7-25ML执行标准西林瓶 7-25ML GBvial

300瓶pcs/分min ～600瓶pcs/分min

≥99%

≤0.1%

300℃-350℃

≤±3%(0.1-10h)

≥99%

100级100c

25m3/H(外配)100cbm/H ～50m3/H(外配)100cbm/H

96kw～235.5kw

380v,50HZ

约 8200KG

约 2000×1750×2370mm
