应用领域与简洁/Brief Introduction：

全系统全自己轴向柱塞泵泵式膏体酱装罐生产线机是我们新公司融入茶叶市场市场潜力开发技术的新设备。什么是服务器用到SUS304不锈钢材质轴向柱塞泵泵式剂量泵施行装罐生产线，且集系统全自己上盖、系统全自己旋盖、机械自动化机械为一梯，市场经济食用，征占户型面积小，广泛性操作于医药、保健食品、药剂、化工环保、化状品等行业领域的固体产品包装，贴合GMP标准请求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

特色/characteristic：

◆主要包括注塞泵式测量泵继续执行灌装设备，应用各种类型乳白色度液态体，高精较高；泵的节构主要包括快接式拆御培训机构，以及难以清理、清洁消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆柱塞泵式测量泵气缸环材料会根据市场及液态体基本成分的不相同主要包括硅硫化橡胶，四氟丁二烯或的材料，非常规在日常生活中主要包括陶瓷厂家材料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC操纵系统化，变频式可控硅调压，自動化层度高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不罐装，手动记数工作。Lack of bottle filling, automatic counting function◆装量调准方便简洁，可是次调准完全收费泵的充填量，也可共性很多收费泵实现微幅调准；控制简单便捷，调准更快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装灌针头安装有防渗漏设施，充填时潜泳到瓶底装灌，很慢飙升，控制起泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆主机可实用有所差异的规格的空瓶，修正操作简单，可在短期间内搞定。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆机器按GMP让开发。The machine designed according to the requirements of GMP

技艺数据/technic parameter：

实用塑料瓶技术参数Size of bottles	20-1000ml（依据符合要求制作厂）20-1000 - ml (according to your need）
适用性玻璃瓶直径为Apply the bottle diameter	¢20-¢150mm
常用盖子外形尺寸Apply the lid specifications	¢20-¢70mm
制造工作能力 production capacity	四头包装：1000-2500瓶/一小时 Four filling head: 1000-2500 bottles per hour 八头装罐：2500-4000瓶/小 Eight head filling: 2500-4000 bottles per hour 12头包装：4000-6000瓶/小时内 12 head filling: 4000-6000 bottles per hour
装量出现偏差的原因The load error	±1%
旋盖优秀率Screw cover percent of pass	≥99%
外接电源power supply	380V，50HZ
耗油率power	3.0KW
安全阀gas sources	0.4-0.75MPA
强度设定speed control	直流变频空调控速variable speed
