使用用途与详细介绍/Brief Introduction：

该设备是加入服食液夹丝朔料瓶子的新商品，已经解决处理解决处理了去年服食液夹丝朔料瓶子的缺陷疗效。这类的灌封机用到的的朔料瓶，不仅不必须 洗瓶机、烘干设备机，更不必须 进行消毒，能否之间灌封。机用户全自動理瓶、进瓶、包装生产线设备，包装生产线设备量比较稳定性，无漏滴，无瓶不包装生产线设备。上盖、密封率达到100%。此机系统现进，面积小、启用比较稳定性、噪音分贝低，操作步骤维护、进行维护清洁更方便等显著特点，已经复合GMP规格。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本型號有底速和髙速不同产能供您确定。Note: this model has two kinds of low speed and high-speed production for your choice.

特性 Characteristic

◆该设备常用到各方面易折瓶内服液计量检测包装和粘口。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆几乎所有电器构件构件均选择着名品店牌。All electrical components adopt famous brand◆该机基本操作主观便宜，无瓶不分装，压力容器检验*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折pp塑胶瓶灌封机的主耍空间结构与方法Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服药液易折塑胶板材瓶灌封机主要的理瓶器、理盖器、主传送机系统、同样带空闲时间送小瓶置、空罐检漏部件、装罐中介构造、删去部件、熔接封中介构造、气动平衡机戒指头夹瓶中介构造、系列伺服变频电动机空闲时间上瓶中介构造与出瓶中介构造等组合而成。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆仪器用的冲剂液易折朔胶瓶、盖是一种定净化区产量的，能有泡脚药材许可证，因此瓶身与底盖经表达和"去外包服务"后可直观步入灌封间。在理盖器、理瓶器的自動定向分配招生整里，去除倒置底盖及瓶身底口朝下的瓶，使定向分配招生后的包材喂料有准则地步入气力输送机行列中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆方向后口服药液易折塑胶板材瓶在输送管导轨里排Directional oral liquid after folding plastic bottles in conveying rail out easily

的技术性能参数technical parameters：

型号model	NLGFY-40	NLGFY-80
装量区间The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
塑封率Hot sealing intensity	》99%
装量出现偏差的原因The load error	《1.5%
脏污率damage rate	《1.0%
效率power	2KW	3KW
电源模块Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
含水量 Weight	700Kg	800Kg
