功用与百度百科/Brief Introduction：

这个机器应用特俗三通管件装罐阀，不适用在水剂和膏霜类產品的装罐，是比较对高凝固点物品（如浓酱、香辛料酱、番茄酱、种衣剂、微乳剂、重新的的隐藏剂等）的治疗效果是比较清晰，且定位精较高。这个机器应用PLC可代码管控，并配6英尺触碰屏电脑软件界面模式，试行重新的的进瓶，重新的的装罐，重新的的出瓶，家用电器，气动系统元零配件均应用亚太茶叶品牌，加强组织领导了卓越的高质量和长时间比较稳定的性能指标。本系统设施设备构造单纯，操作流程省事，是中国大陆非常理想的重视高凝固点物品的装罐系统。这个机器配发了杜绝渗漏与金属拉丝机的装罐闷头，加强组织领导装罐结束之后后无渗漏，无金属拉丝机。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

优缺点/Characteristic：

◆有效操纵系統——采用了三凌PLC有效操纵系統，装灌残留量随机函数上下调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆运行画面——64英寸彩屏手触式运行画面，直观性简洁、安全保障信得过Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆模块优化——上下料有防漏滴设施，可按照原辅料因素拥有下潜装灌模块。（此模块能够所采用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电气电子器件——均采用了国外著名品店牌，狠抓设配的安全保障信得过、更准高；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机制零配件——仪器零配件均利用高品质304不锈碳钢作,知悉要有接觸原物料能能利用316L另结算用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆运算检侧——立即运算，对操作产品的生产数量可以直观表示。Counting test, real-time, intuitive reflect the yield of work.◆灌装生产线查测——无瓶不灌、瓶数不怎么不灌Bottle filling test - no bottle no filling, not enough◆系统维修保养具体情况——机器按照GMP条件，可快速拆御、清洁工作系统维修保养。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆变换型号型号——更改灌装生产线型号型号时，只需要十分简单调正，轻松自由搞掂。Changing specifications - change the filling specifications, simply adjust, easy fix.◆节能显卡设备——显卡设备了节能三层架构，使丝机的进行操作生态环境更好清理卫生管理。（此节能显卡设备可选装）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技能数据/technical parameters：

装灌头数The number of filling head	8头（自选4、6、8、10、13个装灌头）8 heaᩚᩚᩚᩚᩚᩚ⁤⁤⁤⁤ᩚ⁤⁤ꦆ⁤⁤ᩚ⁤⁤⁤⁤ᩚ𒀱ᩚᩚᩚd (optional 4, 6, 8, 10, 12 filling head)
不适用瓶径 Applicable bottles Drive	Ф33-Ф100 mm
计量检定准确度measure precision	±1%
罐装数量Canned capacity	150-1000ml
生育意识Production Capacity	2400-4000瓶/分钟2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
