作用与详细资料/Brief Introduction：

远程服务器组为10-20ml服食液粘液分装研发销售线中的包括环保设备。是由洗瓶、烘干箱功能成大厅触摸三合一机和分装封好成大厅触摸三合一机所組成，能自己完毕服食液瓶的洗瓶、烘干箱功能、分装和封好等运动，是服食液研发销售厂家批发家更好的配置环保设备，仍然合乎GMP条件。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

特征/Characteristic：

◆装量准确，解决漏滴。分装准确度就越高。High filling accuracy.◆变频式无及调速器，生孩子快速可手动调节，要选择区别的生孩子快速。Frequency control, production speed is adjustable, you can choose a different production rate.◆那些电子产品组件均进行出口著名店牌牌子。All electrical components are imported famous brands.◆自动化提示计数器功能性。Automatically countting function.◆控制按照澳大利亚三菱数控系统PLC，抗干忧，事业保持稳定。Controlled by Mitsubishi PLC◆特点不稳，维护维护维护简单。Stable performance, easy maintenance.◆机床样貌所运用SUS304不锈冷库保温隔热板的表层作、与货物沾染这部分所运用316L冷库保温隔热板的表层。机床是按GMP让设计方案。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

新性能参数指标/technical parameters：

使用规模/Bottle size	10-20ml
研发实力/Capacity	60-90瓶/30分钟/60-90bottles/min
烘干功能溫度/Dryer tempreture	100-300°
循环河水量/Water wastage	0.5m3/h
清洁水耗量/Purifying water consumption	0.3m3/h
装量定位精度/Filling precision	≤1%
电/Voltage	380V/50Hz
工作电压/Power	33KW
生产销售线总长/Dimension	3500×1500×1600mm
