作用与简洁/Brief Introduction：

该线由美式丝杠洗瓶干澡整体机、服食液罐装加工线轧盖机二台单机手游游戏结构，包含清理、干澡杀菌和罐装加工线封好六个工做区，全部可联动机制加工，也可单机手游游戏安全使用。可完全淋水、多普勒彩超波清理、冲水、冲气、干澡杀菌、降温、罐装加工线、理盖、戴盖、轧盖等生产工艺。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

的特点/Characteristic：

按照超声心动图波洁净及雾水交叉冲干净、远红外高温作业无菌、双头灌装线与粘口等技能。整线互通自行把控。进行有利有利，保证了机电专业集成化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

科技主要参数/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
适用于规格尺寸 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(这其中一切正常岗位36Kw)(including norm🐈al working 36 kw)
器机总重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
